STAINLESS STEEL PERFORATED TUBE SUPPLIERS INDIA

STAINLESS STEEL PERFORATED EXHAUST TUBE, PERFORATED 304 STAINLESS STEEL TUBING, STAINLESS STEEL PERFORATED ROUND TUBING MANUFACTURER IN INDIA


316 STAINLESS STEEL PERFORATED TUBE DEALER, STAINLESS STEEL SEAMLESS PERFORATED TUBE IMPORTER, STAINLESS STEEL PERFORATED SQUARE TUBE, 2 PERFORATED STAINLESS STEEL TUBE EXPORTER IN INDIA


KAMAL STEEL INDUSTRIES is one of the most trusted supplier & exporter of Stainless Steel Perforated Tube in a number of standard grades and sizes. Our stock of SS Perforated Tube primarily consists of the austenitic grades of stainless steel including TP304L, TP304, TP316L, TP316, and TP201 in annealed and pickled, bright annealed, mill finish. 304 stainless steel perforated tube to support the filter media in making of various filter elements. Using of perforated metal adds more pressure and strength resistance in filter flow. Our offered 316 stainless steel perforated tube is mostly used in filter products as support tubing, and sometimes it is used directly as filter tubes and cylinders for certain industries..We are also well known as perforated stainless steel square tube Manufacturer in India. Buy SS Perforated tubing at best price in India from us as compared to the market price.


Stainless Steel Perforated Tube

Stainless Steel Perforated Tube

SS 304 Perforated Tube

SS 304 Perforated Tube

SS 316L Perforated Tube

SS 316L Perforated Tube


STAINLESS STEEL PERFORATED TUBE SPECIFICATION

Stainless Steel Poished Tube ASTM  ASTM A249, A269, A270
OD. 1/8” NB to 24” NB, 1/4” OD to 24” OD sizes stainless steel welded tubes also available
Thickness  0.2mm to 15mm
Hole size 3mm dia on a 6mm pitch
Opening diameter 0.2mm to 100mm
Material SS 304, SS 304L,SS 316,SS 316L, SS201
Finish BA Finish inside and outside, Perforated finish inside and outside
Type As Welded, EFW, ERW, Seamless, Semi Seamless, Bead Removed
Mill Test Certificate EN10204 3.1
Packing Sleeved, Ends Capped, Wooden Boxed




As the largest stockholder of stainless steel Perforated Tube includes grades Stainless Steel 316 Perforated Tube, Stainless steel 316L Perforated Tube, 304L Perforated Tube, and Stainless Steel 201 Perforated Tube those are used in various industrial applications.

Stainless Steel Perforated Tube Manufacturer in India, SS Perforated Tubes, SS Perforated Tube Dealer in India, High Quality Stainless Steel Perforated Tube, Stainless Steel Perforated Tubes Exporter in India, Perforated Stainless Steel Tubing, Welded Stainless Steel Perforated Tubes.

SUPPLIERS OF STAINLESS STEEL PERFORATED TUBES, 304 PERFORATED STEEL TUBES, STAINLESS STEEL PERFORATED TUBE EXPORTER, SS 304 PERFORATED TUBE IMPORTER, SS 316 PERFORATED TUBE SUPPLIER IN MUMBAI, INDIA.



TYPES OF STAINLESS STEEL PERFORATED TUBE



SS 201 Perforated Tube
SS 304 Perforated Tube
SS 304L Perforated Tube
SS 316 Perforated Tube



SS 316L Perforated Tube
SS Seamless Perforated Tube
SS Perforated Tube
Perforated Steel Tube



SS PERFORATED TUBE SIZES

Stainless steel Perforated Tubes are finished in accordance with customer needs regarding dimensional and wall thickness specifications as well as heat treatment for more demanding applications. In general a stainless steel Perforated Tube is manufactured according to current standards API, ASTM, and ASME. If required for special projects we can also supply large diameter Perforated Tubes.

SS PERFORATED TUBE STANDARD SIZES, WEIGHT CHART

Exhaust Stainless Steel PERFORATED TUBE:OD 38.01 MM OR
11/2" INCH 1 X METER LONG
304 PERFORATED TUBE 11/2 INCH OD (38.01 MM) 1 METER LONG
Exhaust Stainless Steel Perforated Tube OD 88.9 MM OR 31/2" INCH 1 X METER LONG
304 PERFORATED TUBE 31/2 INCH OD (88.9 MM) 1 METER LONG
Exhaust Stainless Steel Perforated Tube OD 101.60 MM OR 4" INCH 1 X 500MM LONG
304 PERFORATED TUBE 4 INCH OD (101.60 MM) 1 X 500MM LONG
Exhaust Stainless Steel Perforated Tube OD 88.9 MM OR 31/2" INCH 1 X 500MM LONG
304 PERFORATED TUBE 31/2 INCH OD (88.9 MM) 1 X 500MM LONG
Exhaust Stainless Steel Perforated Tube OD 76.2 MM OR 3" INCH 1 X 500MM LONG
304 PERFORATED TUBE 3 INCH OD (76.2 MM) 1 X 500MM LONG
Exhaust Stainless Steel Perforated Tube OD 76.2 MM OR 3" INCH 1 X 500MM LONG
304 PERFORATED TUBE 3 INCH OD (76.2 MM) 1 X 500MM LONG
Exhaust Stainless Steel Perforated Tube OD 57.15 MM OR 21/4" INCH 1 X 500MM LONG
304 PERFORATED TUBE 21/4 INCH OD (57.15 MM) 1 X 500MM LONG
Exhaust Stainless Steel Perforated Tube OD 50.8 MM OR 2" INCH 500MM LONG
304 PERFORATED TUBE 2 INCH OD (50.8 MM) 500MM LONG
Exhaust Stainless Steel Perforated Tube OD 38.01 MM OR 11/2" INCH 500MM LONG
304 PERFORATED TUBE 11/2 INCH OD (38.01 MM) 500MM LONG
Exhaust Stainless Steel Perforated Tube OD 76.2 MM OR 3" INCH 1 X METER LONG
304 PERFORATED TUBE 3 INCH OD (76.2 MM) 1 METER LONG
Exhaust Stainless Steel Perforated Tube OD 63.5 MM OR 21/2" INCH 1 X METER LONG
304 PERFORATED TUBE 21/2 INCH OD (63.5 MM) 1 METER LONG



STAINLESS STEEL PERFORATED TUBE DIAMETER,WEIGHT CHART

Stainless Steel Perforated Tube Lbs. Per Square Foot
Gauge Mean of Gauge Min. of Gauge Max. of Gauge 300 Series 400 Series
7 .1875 .1735 .2015 7.871 7.70
8 .1650 .1510 .1790 6.930 6.78
9 .150 .136 .164 6.300 6.165
10 .135 .129 .141 5.670 5.562
11 .120 .115 .125 5.040 4.944
12 .1054 .1004 .1104 4.427 4.342
13 .090 .0860 .094 3.780 3.708
14 .0751 .0711 .0791 3.154 3.094
15 .0673 .0643 .0703 2.826 2.766
16 .0595 .0565 .0625 2.499 2.451
17 .0538 .0508 .0568 2.259 2.211
18 .048 .045 .051 2.016 1.978
19 .042 .039 .045 1.764 1.726
20 .0355 .0335 .0375 1.491 1.463
21 .0324 .0304 .0344 1.360 1.33
22 .0293 .0273 .0313 1.231 1.207
23 .0264 .0249 .0279 1.1088 1.085
24 .0235 .0220 .0250 .987 .968
25 .0209 .0194 .0224 .8778 .8589
26 .0178 .0163 .0193 .748 .7315
27 .0165 .0150 .0180 .693 .6781
28 .0151 .0136 .0166 .634 .6206
29 .0138 .0123 .0153 .5796 .5671
30 .0125 .0110 .0140 .525 .5137



STAINLESS STEEL PERFORATED TUBE SIZE / DIMENSIONS / WEIGHT CHART

GAUGE

HOLES

CENTERS

OPEN AREA %

30

.020"

.045"

20%

26

1/32"

1/16"

22%

26

.033"

.055" STRAIGHT

29%

24

3/64"

3/32"

23%

26

.050"

.066" STRAIGHT

52%

26

050"

5/64"

37%

22

1/16"

3/32"

40%

22,26

1/16"

7/64"

30%

20,18

1/16"

1/8"

23%

22,20

5/64

1/8"

35%

20,18,16

3/32

5/32"

33%

22

.117

5/32"

51%

26-11

1/8

3/16"

40%

20-16

5/32"

3/16"

63%

24-14

3/16"

1/4"

51%

18,11

3/16"

5/16"

33%

22-16

1/4"

5/16"

58%

20-14,11

1/4"

3/8"

40%

10

3/8"

1/2"

51%

18,16,11

3/8"

9/16"

40%

20,16,14,11

1/2"

11/16"

48%

11

3/4"

1"

51%



STAINLESS STEEL PERFORATED TUBE SCHEDULE CHART

NB SIZES SCH 5 SCH 10 SCH 40 SCH 80 SCH 160
1/8″

1/4″

3/8″

1/2″
3/4″
1″
1 1/4″
1 1/2″
2″
2 1/2″
3″
4″
5″

6″




STAINLESS STEEL PERFORATED TUBE PRESSURE RATING

AVE. WALL INCHES MIN YIELD STRENGTH (PSI) MIN TENSILE STRENGTH (PSI) THEORETICAL BURST PRESSURE * (PSI) WORKING PRESSURE (PSI) 25% OF BURST THEORETICAL YIELD POINT ** (PSI) COLLAPSE PRESSURE *** (PSI)
0.250 0.020 30,000 75,000 14,286 3,571 5,714 4,416
0.250 0.028 30,000 75,000 21,649 5,412 8,660 5,967
0.250 0.035 30,000 75,000 29,167 7,292 11,667 7,224
0.250 0.049 30,000 75,000 48,355 12,089 19,342 9,455
0.250 0.065 30,000 75,000 81,250 20,313 32,500 11,544
0.375 0.020 30,000 75,000 8,955 2,239 3,582 3,029
0.375 0.028 30,000 75,000 13,166 3,292 5,266 4,145
0.375 0.035 30,000 75,000 17,213 4,303 6,885 5,077
0.375 0.049 30,000 75,000 26,534 6,634 10,614 6,816
0.375 0.065 30,000 75,000 39,796 9,949 15,918 8,597
0.500 0.020 30,000 75,000 6,522 1,630 2,609 2,304
0.500 0.028 30,000 75,000 9,459 2,365 3,784 3,172
0.500 0.035 30,000 75,000 12,209 3,052 4,884 3,906
0.500 0.049 30,000 75,000 18,284 4,571 7,313 5,304
0.500 0.065 30,000 75,000 26,351 6,588 10,541 6,786
0.500 0.083 30,000 75,000 37,275 9,319 14,910 8,307
0.625 0.020 30,000 75,000 5,128 1,282 2,051 1,859
0.625 0.028 30,000 75,000 7,381 1,845 2,953 2,568
0.625 0.035 30,000 75,000 9,459 2,365 3,784 3,172
0.625 0.049 30,000 75,000 13,947 3,487 5,579 4,335
0.625 0.065 30,000 75,000 19,697 4,924 7,879 5,591
0.625 0.083 30,000 75,000 27,124 6,781 10,850 6,910
0.625 0.095 30,000 75,000 32,759 8,190 13,103 7,734
0.625 0.109 30,000 75,000 40,172 10,043 16,069 8,639
0.750 0.028 30,000 75,000 6,052 1,513 2,421 2,156
0.750 0.035 30,000 75,000 7,721 1,930 3,088 2,669
0.750 0.049 30,000 75,000 11,273 2,818 4,509 3,664
0.750 0.065 30,000 75,000 15,726 3,931 6,290 4,749
0.750 0.083 30,000 75,000 21,318 5,330 8,527 5,905
0.750 0.095 30,000 75,000 25,446 6,362 10,179 6,637
0.750 0.109 30,000 75,000 30,733 7,683 12,293 7,453
0.750 0.120 30,000 75,000 35,294 8,824 14,118 8,064
0.875 0.020 30,000 75,000 3,593 898 1,437 1,340
0.875 0.028 30,000 75,000 5,128 1,282 2,051 1,859
0.875 0.035 30,000 75,000 6,522 1,630 2,609 2,304
0.049 30,000 75,000 9,459 2,365 3,784 3,172
0.875 0.065 30,000 75,000 13,087 3,272 5,235 4,126
0.875 0.083 30,000 75,000 17,560 4,390 7,024 5,152
0.875 0.095 30,000 75,000 20,803 5,201 8,321 5,807
0.875 0.109 30,000 75,000 24,886 6,221 9,954 6,543
0.875 0.120 30,000 75,000 28,346 7,087 11,339 7,100
1.000 0.028 30,000 75,000 4,449 1,112 1,780 1,633
1.000 0.035 30,000 75,000 5,645 1,411 2,258 2,027
1.000 0.049 30,000 75,000 8,149 2,037 3,259 2,796
1.000 0.065 30,000 75,000 11,207 2,802 4,483 3,647
1.000 0.083 30,000 75,000 14,928 3,732 5,971 4,567
1.000 0.095 30,000 75,000 17,593 4,398 7,037 5,159
1.000 0.109 30,000 75,000 20,908 5,227 8,363 5,827
1.000 0.120 30,000 75,000 23,684 5,921 9,474 6,336
1.000 0.134 30,000 75,000 27,459 6,865 10,984 6,963
1.250 0.035 30,000 75,000 4,449 1,112 1,780 1,633
1.250 0.049 30,000 75,000 6,380 1,595 2,552 2,260



STAINLESS STEEL PERFORATED TUBE DIMENSIONAL TOLERANCES

SIZE OD   NOMINAL WALL THICKNESS   OUTSIDE DIAMETER TOLERANCE   LENGTH TOLERANCE   WALL THICKNESS TOLERANCE
(in) (mm) (in) (mm) (in) (mm) (in) (mm) (%)
½ 12.7 0.065 1.65 +/-0.005 +/-0.13 +⅛, -0 +3.18, -0 +/-10.0%
¾ 19.1 0.065 1.65 +/-0.005 +/-0.13 +⅛, -0 +3.18, -0 +/-10.0%
1 25.4 0.065 1.65 +/-0.005 +/-0.13 +⅛, -0 +3.18, -0 +/-10.0%
38.1 0.065 1.65 +/-0.008 +/-0.20 +⅛, -0 +3.18, -0 +/-10.0%
2 50.8 0.065 1.65 +/-0.008 +/-0.20 +⅛, -0 +3.18, -0 +/-10.0%
63.5 0.065 1.65 +/-0.010 +/-0.25 +⅛, -0 +3.18, -0 +/-10.0%
3 76.2 0.065 1.65 +/-0.010 +/-0.25 +⅛, -0 +3.18, -0 +/-10.0%
4 101.6 0.083 2.11 +/-0.015 +/-0.38 +⅛, -0 +3.18, -0 +/-10.0%
6 152.4 0.109 2.77 +/-0.030 +/-0.76 +1, -0 +25.4, -0 +/-10.0%



STAINLESS STEEL PERFORATED TUBE CHEMICAL COMPOSITION

The below table shows the chemical composition of the used for Stainless Steel PERFORATED Tubes:

GRADES UNS C Mn P S Si Cr Ni Mo Ti Nb N
TP304 S30400 0.08 2 0.045 0.03 1 18.0-20.0 8.0-11.0
TP304L S30403 0.035 2 0.045 0.03 1 18.0-20.0 8.0-13.0
TP316 S3160 0.08 2 0.045 0.03 1 16.0-18.0 11.0-14.0 2.0-3.0
TP316L S31603 0.035 2 0.045 0.03 1 16.0-18.0 10.0-14.0 2.0-3.0



SS PERFORATED TUBE MECHANICAL PROPERTIES

Material Heat Temperure Tensile Strength Yield Strength Elongation %, Min
Treatment Min. Ksi (MPa), Min. Ksi (MPa), Min.
  º F(º C)
TP304 Solution 1900 (1040) 75(515) 30(205) 35
TP304L Solution 1900 (1040) 70(485) 25(170) 35
TP316 Solution 1900(1040) 75(515) 30(205) 35
TP316L Solution 1900(1040) 70(485) 25(170) 35



STAINLESS STEEL PERFORATED TUBING EQUIVALENT GRADES

GRADE UNS NO DIN/WERKSTOFF
304 S30400 1.4301
304L S30403 1.4306
316 S31600 1.4436
316L S31603 1.4404



AVAILABLE STOCK OF SS PERFORATED TUBE

SS Perforated Tube Importer Bright Perforated SS Tube Supplier & Manufacturer in India
304 SS Brush Finish Perforated Tube Supplier & Manufacturer in Indias Dull Perforated SS Tube Manufacturer
SS Seamless Perforated Tube Supplier & Manufacturer in India SS Perforated Tubing for Food Grade
Seamless SS Perforated Tube Supplier & Manufacturer in India High Perforated SS Perforated Tube Trader
SS Perforated Tube Manufacturer in India SS Welded Perforated Tube Exporter
SS Perforated Tube Manufacturer in India 316 SS Perforated Tube Supplier & Manufacturer in India
Perforated 304 SS Tube Supplier & Manufacturer in India 25mm Perforated SS Tube Supplier & Manufacturer in India
SS Perforated tubing stockist 22mm Perforated SS Tube Supplier & Manufacturer in India
SS Perforated tubing Supplier & Manufacturer in India SS Welded Perforated Tube Supplier & Manufacturer in India
SS welded Perforated Tube Supplier & Manufacturer in India SS Seamless Electro Perforated Tube Exporter
Steel Perforated tubing Supplier & Manufacturer in India Perforated SS Tube Price





STAINLESS STEEL PERFORATED TUBE PRICE LIST



STAINLESS STEEL PERFORATED TUBES STOCK SUPPLY APPLICATIONS

These stainless steel Perforated Tubes are sold to a wide range of industries/markets, due to their overall corrosion resistance and good machinability:
