Stainless Steel Supplier

Stainless Steel Grades,Stainless Steel Price, Stainless Steel Stockist in India,Stainless Steel Composition,Stainless Steel Properties



KAMAL STEEL is one one of the most reliable and trusted stockist, supplier, and Exporter of Stainless Steel Materials that are actually manufactured from High Quality of Standard Raw Materials are designed as per with national and international standards. Our offered stainless steel products like, Stainless Steel Pipe and Stainless Steel Tube are used for piping systems where resistance to stress-corrosion cracking is required. The product range includes 316/316L Pipes, 304/304L Pipes,201 Pipes in custom-made sizes and shapes as per the requirements are given by our clients and that too at an affordable and market leading prices.

What is Stainless Steel?

Stainless steel usually containing 10 to 30 percent chromium. In conjunction with low carbon content, chromium imparts remarkable resistance to heat and corrosion. Other elements, such as aluminum, sulfur, copper, nitrogen, molybdenum, titanium, niobium, phosphorus, or selenium, may be added to increase corrosion resistance to specific environments, enhance oxidation resistance, and impart special characteristics. It was a generic name for these steels and now covers a wide range of steel types and grades for corrosion or oxidation resistant applications.

The grade most often used is Grade 304 (1.4301) for corrosion resistant reinforcement, suitable for most atmospheric and concrete covered environments.

TheGrade 316 (1.4401) has a higher molybdenum and nickel content than 304 (1.4301). It is more expensive but also has higher corrosion resistance and is the recommended grade for marine and corrosive environments.




Stainless Steel Grades

GRADE OVERVIEW
300 Series 301 – 302 – 303 – 304/L – 304H – 316/L – 317L – 317LMN – 321 – 321H – 347 – 347H
300 Series High Temp 309 – 309S – 310 – 310S – 310H – 330
400 Series 403 – 405 – 409 – 410 – 410S – 410HT – 416 – 416HT – 420 – 422 – 430 – 440C
Duplex  2205 – 2304 – 2507 – LDX2101



Chemical Composition

The below table shows the chemical composition of the most used A312 Stainless Steel Pipes:

A312 GRADES UNS C Mn P S Si Cr Ni Mo Ti Nb N
TP304 S30400 0.08 2 0.045 0.03 1 18.0-20.0 8.0-11.0
TP304L S30403 0.035 2 0.045 0.03 1 18.0-20.0 8.0-13.0
TP316 S3160 0.08 2 0.045 0.03 1 16.0-18.0 11.0-14.0 2.0-3.0
TP316L S31603 0.035 2 0.045 0.03 1 16.0-18.0 10.0-14.0 2.0-3.0
TP321 S3210 0.08 2 0.045 0.03 1 17.0-19.0 9.0-12.0 0.1
TP321H S32109 0.04-0.10 2 0.045 0.03 1 17.0-19.0 9.0-12.0 0.1
TP347 S3470 0.08 2 0.045 0.03 1 17.0-19.0 9.0-13.0



Mechanical Properties

Material Heat Temperure Tensile Strength Yield Strength Elongation %, Min
Treatment Min. Ksi (MPa), Min. Ksi (MPa), Min.
º F(º C)
TP304 Solution 1900 (1040) 75(515) 30(205) 35
TP304L Solution 1900 (1040) 70(485) 25(170) 35
TP316 Solution 1900(1040) 75(515) 30(205) 35
TP316L Solution 1900(1040) 70(485) 25(170) 35



Military Specification stainless Pipe & Tubing
Specification Type Analysis Service
MIl-P-1144 Seamless Or Welded Stainless-All Grades High Temperature & Pressure
MIl-P-24691/3 Seamless Stainless-All Grades High Temperature & Pressure
MIl-T-8504/AMS-5567 Seamless Or Welded Type 304 Corrosion & Hydraulic
MIl-T-8606/AMS-5560 Seamless 321,347,304L Stainless Corrosion Applications
MIl-T-8808/AMS-5570 Seamless 321 & 347 Stainless Corrosion Applications
MIl-T-16286 Seamless Class C Type 321 Or 347 High Pressure Steam &
Super Heater Generator
MIl-T-16286 Seamless Class E & F Chrome Moly High Temperature & Pressure
MIl-T-23226 Seamless Type 304, 304L, 347 High Pressure Steam &
Super Heater Generator
