KAMAL STEEL INDUSTRIES is a well-known manufacturer, supplier, and exporter of ASME SA554 TP316. We offer ASTM A554 TP316 specification covers welded austenitic, ferritic, and austenitic-ferritic duplex stainless steel mechanical tubing intended for use in the ornamental, structural, exhaust, and other applications where appearance, mechanical properties, or corrosion resistance is needed. SA554 TP316 Tubing is commonly shipped without protective coating. If special protection is needed, details shall be specified in the order. ASME SA554 TP316 Rectangular Tube and ASTM A554 TP316 Square Tubing yield strength corresponding to a permanent offset of 0.2% of the gage length of the specimen, to a total extension of 0.5% of the gage length under load shall be determined. ASTM A554 Grade mt316 is made from flat-rolled steel by an automatic welding process, without any filler metal addition. Heat analysis is performed so that several grades of stainless steel conforming to the required chemical composition.


ASTM A554 TP316 Tubing

ASTM A554 TP316 Tubing

ASTM A554 TP316  Tube

ASTM A554 TP316 Tube

ASTM A554 TP316 Welded Tube

ASTM A554 TP316 Welded Tube


ASTM A554 TP316 STAINLESS STEEL TUBE SPECIFICATION

Method  TIG or TIG + Plasma or Laser
Finish 2B MIll Finish , No.4 finish, BA Finish, 400 Grit Finish, 550 Grit Finish, 600 Grit Finish
Grades ASTM A554 ( MT304/316, MT316/316L ),JIS G3446 ( SUS316TK, SUS316TK ), CNS 5802 ( 316TK, 316TK ), (YC1)
Size 6NB to 1200NB IN
O.D. 9.5mm ~ 139.7mm
Wall Thickness 0.6 ~ 3.05mm
Length Single Random, Double Random & Cut Length
Types Round, Square, Rectangle, Coil, "U" Shape, Hydraulic & Honed Tubes
Specifications ASTM A554 TP316/ ASME SA554 TP316
Schedule SCH. 5, 10, 20, 30, 40, 60, 80, 100, 120, 140, 160, XXS.
ASTM A554 TP316 Products ASTM A554 316 Stainless Steel Polished Tubes, ASTM A554 TP316 Polished Tubes, ASTM A554 TP316 No.4 Finish Tube, ASTM A554 TP316 Polished Tubes, ASTM A554 TP316 Tubing, ASTM A554 TP316 Welded Mechanical Tubing, ASTM A554 TP316 Welded Polished Tubes, ASTM A554 TP316 Stainless Steel Square Tube, ASTM A554 TP316 Mirror Polished Austenitic Stainless Steel Tubes for Decoration, ASTM A554 TP316 Square Tube

ASTM A554 TP316 Stainless Steel Tubes, ASTM A554 TP316 Square Stainless Steel Tubing, ASTM A554 TP316 Stainless Welded Tubes, ASTM A554 TP316 Stainless Steel Tubing, ASTM A554 TP316 SS Tubes, ASTM A554 TP316 SS Tubing, ASTM A554 TP316 Cold Draw Seamless Tubes, ASTM A554 TP316 Stainless Steel ERW Tubes

SUPPLIERS OF ASTM A554 TP316 SQUARE TUBING,ASTM A554 TP316 STAINLESS STEEL EXHAUST TUBE,ASTM A554 TP316 ORNAMNETAL STAINLESS STEEL TUBE EXPORTER, ASTM A554 TP316 ROUND TUBING SUPPLIER IN MUMBAI, INDIA.



TYPES OF ASTM A554 TP316 STAINLESS STEEL TUBE



ASTM A554 Hollow Tube
ASTM A554 square Tube
ASTM A554 Seamless Tube
ASTM A554 Round Tub



ASTM A554 Rectangular Tube
ASTM A554 Capillary
ASTM A554 U Tube
ASTM A554 Perofrated



ASTM A554 Boiler Tube
ASTM A554 Decorative Tube
ASTM A554 Exhaust Tube

ASTM A554 Oval Tube
ASTM A554 Polished Tube
ASTM A554 Condenser Tube




ASTM A554 TP316 STAINLESS STEEL TUBE SIZES

ASTM A554 TP304L SS tubes are finished in accordance with customer needs regarding dimensional and wall thickness specifications as well as heat treatment for more demanding applications. In general a ss seamless tube is manufactured in sizes from 1/2” to 8”NB according to current standards ASTM, API, and ASME.

ASTM A554 TP316 TUBE DIMENSIONS AND WEIGHTS

DIMENSIONS OF ASTM A554 WELDED MECHANICAL TUBING OUTSIDE AND INSIDE DIAMETER OR WALL

OD Size, in. (mm)

OD, ±in.

mm

ID, ±in.

mm

Up to 3⁄32 (2.4), excl

0.001

0.03

0.001

0.03

3⁄32 to 3⁄16 (2.4 to 4.8), excl

0.0015

0.038

0.0015

0.038

3⁄16 to 1⁄2 (4.8 to 12.7), excl

0.003

0.08

0.005

0.13

1⁄2 to 1 (12.7 to 25.4), excl

0.004

0.10

0.006

0.15

1 to 11⁄2 (25.4 to   38.1),excl

0.005

0.13

0.007

0.18

1 1⁄2 to 2 (38.1 to 50.8),excl

0.006

0.15

0.008

0.20

2 to 2 1⁄2 (50.8 to 63.5),excl

0.007

0.18

0.010

0.25

2 1⁄2 to 3 1⁄2 (63.5 to 88.9),excl

0.010

0.25

0.014

0.36

3 1⁄2 to 5 (88.9 to 127.0),incl

0.015

0.38

0.020

0.51

Over 5 to 16 (127.0 to 406.4), incl

0.00125 in./in. or mm/mm of cir-cumference

0.0013 in./in. or mm/mm of cir-cumference





ASTM A554 TP316 Stainless Steel Square Tube Dimensions
Tube Thickness (mm)
Outside Diameter
(in)
Outside Diameter
(mm)
0.6 0.7 0.8 0.9 1.0 1.2-1.25 1.5 1.6-1.65 2.0-2.11 2.5 3.0-3.05 4.00 5.00 6.00
1/2"x 1/2" 12.7x 12.7
- 15.0x 15.0
- 18.0x 18.0
3/4''x 3/4' 19.0x 19.0
- 20.0x 20.0
- 25.0x 25.0
1"x 1" 25.4x 25.4
- 30.0x 30.0
1 1/4"x 1 1/4" 31.8x 31.8
1 1/2"x 1 1/2" 38.1x 38.1
- 40.0x 40.0
- 50.0x 50.0
2"x 2" 50.8x 50.8
- 60.0x 60.0
- 70.0x 70.0
- 75.0x 75.0
- 80.0x 80.0
- 90.0x 90.0
- 100x 100
Remark (1)Marking:Product SPEC.
(2)Finish : ( ☆: Polish#180#320) ; (△ : Polish #180#320#400)



ASTM A554 TP316 Square Stainless Steel Tube - Sizes & Weights per foot
ASTM A554 TP316 Polished Square Tube

Gauge  18 16 14 11 7  1/4  3/8
Inches 0.049 0.065 0.083 0.120 0.180 0.250 0.375

1/2 0.30 0.39
5/8 0.38 0.40
3/4 0.50 65.00 0.81 1.13
1 0.63 0.83 1.03 1.45 2.17
1-1/4 0.82 1.08 1.37 1.93 2.99
1-1/2 0.97 1.27 1.61 2.26 3.63 4.41
1-3/4 1.13 1.49 1.88 2.66 3.75
2 1.30 1.69 2.14 3.06 4.46 6.01
2-1/2     2.72 3.88 5.68 7.67
3     3.29 4.97 6.90 9.35
3-1/2       5.67 8.06 10.89
4       6.26 9.27 12.68 18.52
5       8.02 11.90 16.35 23.53
6       9.46 14.07 18.77 28.53
8           26.03 38.55



ASTM A554 TP316 STAINLESS STEEL TUBE SCHEDULE CHART

NB SIZES SCH 5 SCH 10 SCH 40 SCH 80 SCH 160
1/8″

1/4″

3/8″

1/2″
3/4″
1″
1 1/4″
1 1/2″
2″
2 1/2″
3″
4″
5″

6″




ASTM A554 TP316 TUBE PRESSURE RATING

TUBE PRESSURE RATING FOR ASTM A554 TP316

OD inches Ave. Wall inches Min Yield Strength (PSI) Min Tensile Strength (PSI) Theoretical Burst Pressure * (PSI) Working Pressure (PSI) 25% of Burst Theoretical Yield Point ** (PSI) Collapse Pressure *** (PSI)
0.250 0.020 30,000 75,000 14,286 3,571 5,714 4,416
0.250 0.028 30,000 75,000 21,649 5,412 8,660 5,967
0.250 0.035 30,000 75,000 29,167 7,292 11,667 7,224
0.250 0.049 30,000 75,000 48,355 12,089 19,342 9,455
0.250 0.065 30,000 75,000 81,250 20,313 32,500 11,544
0.375 0.020 30,000 75,000 8,955 2,239 3,582 3,029
0.375 0.028 30,000 75,000 13,166 3,292 5,266 4,145
0.375 0.035 30,000 75,000 17,213 4,303 6,885 5,077
0.375 0.049 30,000 75,000 26,534 6,634 10,614 6,816
0.375 0.065 30,000 75,000 39,796 9,949 15,918 8,597
0.500 0.020 30,000 75,000 6,522 1,630 2,609 2,316
0.500 0.028 30,000 75,000 9,459 2,365 3,784 3,172
0.500 0.035 30,000 75,000 12,209 3,052 4,884 3,906
0.500 0.049 30,000 75,000 18,284 4,571 7,313 5,316
0.500 0.065 30,000 75,000 26,351 6,588 10,541 6,786
0.500 0.083 30,000 75,000 37,275 9,319 14,910 8,307
0.625 0.020 30,000 75,000 5,128 1,282 2,051 1,859
0.625 0.028 30,000 75,000 7,381 1,845 2,953 2,568
0.625 0.035 30,000 75,000 9,459 2,365 3,784 3,172
0.625 0.049 30,000 75,000 13,947 3,487 5,579 4,335
0.625 0.065 30,000 75,000 19,697 4,924 7,879 5,591
0.625 0.083 30,000 75,000 27,124 6,781 10,850 6,910
0.625 0.095 30,000 75,000 32,759 8,190 13,103 7,734
0.625 0.109 30,000 75,000 40,172 10,043 16,069 8,639
0.750 0.028 30,000 75,000 6,052 1,513 2,421 2,156
0.750 0.035 30,000 75,000 7,721 1,930 3,088 2,669
0.750 0.049 30,000 75,000 11,273 2,818 4,509 3,664
0.750 0.065 30,000 75,000 15,726 3,931 6,290 4,749
0.750 0.083 30,000 75,000 21,318 5,330 8,527 5,905
0.750 0.095 30,000 75,000 25,446 6,362 10,179 6,637
0.750 0.109 30,000 75,000 30,733 7,683 12,293 7,453
0.750 0.120 30,000 75,000 35,294 8,824 14,118 8,064
0.875 0.020 30,000 75,000 3,593 898 1,437 1,340
0.875 0.028 30,000 75,000 5,128 1,282 2,051 1,859
0.875 0.035 30,000 75,000 6,522 1,630 2,609 2,316
0.875 0.049 30,000 75,000 9,459 2,365 3,784 3,172
0.875 0.065 30,000 75,000 13,087 3,272 5,235 4,126
0.875 0.083 30,000 75,000 17,560 4,390 7,024 5,152
0.875 0.095 30,000 75,000 20,803 5,201 8,321 5,807
0.875 0.109 30,000 75,000 24,886 6,221 9,954 6,543
0.875 0.120 30,000 75,000 28,346 7,087 11,339 7,100
1.000 0.028 30,000 75,000 4,449 1,112 1,780 1,633
1.000 0.035 30,000 75,000 5,645 1,411 2,258 2,027
1.000 0.049 30,000 75,000 8,149 2,037 3,259 2,796
1.000 0.065 30,000 75,000 11,207 2,802 4,483 3,647
1.000 0.083 30,000 75,000 14,928 3,732 5,971 4,567
1.000 0.095 30,000 75,000 17,593 4,398 7,037 5,159
1.000 0.109 30,000 75,000 20,908 5,227 8,363 5,827
1.000 0.120 30,000 75,000 23,684 5,921 9,474 6,336
1.000 0.134 30,000 75,000 27,459 6,865 10,984 6,963
1.250 0.035 30,000 75,000 4,449 1,112 1,780 1,633
1.250 0.049 30,000 75,000 6,380 1,595 2,552 2,260
1.250 0.065 30,000 75,000 8,705 2,176 3,482 2,958
1.250 0.083 30,000 75,000 11,485 2,871 4,594 3,719
1.250 0.095 30,000 75,000 13,443 3,361 5,377 4,213
1.250 0.109 30,000 75,000 15,843 3,961 6,337 4,776
1.250 0.120 30,000 75,000 17,822 4,455 7,129 5,207
1.250 0.134 30,000 75,000 20,468 5,117 8,187 5,742
1.500 0.035 30,000 75,000 3,671 918 1,469 1,367
1.500 0.049 30,000 75,000 5,243 1,311 2,097 1,896
1.500 0.065 30,000 75,000 7,117 1,779 2,847 2,487
1.500 0.083 30,000 75,000 9,333 2,333 3,733 3,136
1.500 0.095 30,000 75,000 10,878 2,719 4,351 3,559
1.500 0.109 30,000 75,000 12,754 3,188 5,101 4,043
1.500 0.120 30,000 75,000 14,286 3,571 5,714 4,416
1.500 0.134 30,000 75,000 16,315 4,079 6,526 4,881
1.500 0.148 30,000 75,000 18,439 4,610 7,375 5,336
1.750 0.035 30,000 75,000 3,125 781 1,250 1,176
1.750 0.049 30,000 75,000 3,864 966 1,546 1,434
1.750 0.065 30,000 75,000 6,019 1,505 2,407 2,146
1.750 0.083 30,000 75,000 7,860 1,965 3,144 2,711
1.750 0.095 30,000 75,000 9,135 2,284 3,654 3,080
1.750 0.109 30,000 75,000 10,672 2,668 4,554 3,504
1.750 0.120 30,000 75,000 11,921 2,980 4,768 3,832
1.750 0.134 30,000 75,000 13,563 3,391 5,425 4,242
1.750 0.148 30,000 75,000 15,268 3,817 6,107 4,645
1.750 0.165 30,000 75,000 17,430 4,357 6,972 5,124
2.000 0.035 30,000 75,000 2,720 680 1,088 1,032
2.000 0.049 30,000 75,000 3,864 966 1,546 1,434
2.000 0.065 30,000 75,000 5,214 1,303 2,086 1,887
2.000 0.083 30,000 75,000 6,788 1,697 2,715 2,387
2.000 0.095 30,000 75,000 7,873 1,968 3,149 2,715
2.000 0.109 30,000 75,000 9,175 2,294 3,670 3,092
2.000 0.120 30,000 75,000 10,227 2,557 4,091 3,384
2.000 0.134 30,000 75,000 11,605 2,901 4,642 3,751
2.000 0.148 30,000 75,000 13,028 3,257 5,211 4,111
2.000 0.165 30,000 75,000 14,820 3,705 5,928 4,542



ASTM A554 TP316 STAINLESS STEEL TUBE TOLERANCES

Tolerances — Diameter, Wall— Round Tube
OD Size
Inches
Wall Thickness
OD
± Inches
Under 1/2
0.020 to 0.049
0.004
1/2 to 1
0.020 to0.065
0.005
1/2 to 1
over 0.065 to 0.134
0.010
Over 1 to 1-1/2
0.025 to 0.065
0.008
Over 1 to 1-1/2
over 0.065 to 0.134
0.010
Over 1-1/2 to 2
0.025 to 0.049
0.010
Over 1-1/2 to 2
over 0.049 to 0.083
0.011
Over 1-1/2 to 2
over 0.083 to 0.149
0.012
Over 2 to 2-1/2
0.032 to 0.065
0.012
Over 2 to 2-1/2
over 0.065 to 0.109
0.013
Over 2 to 2-1/2
over 0.109 to 0.165
0.014
Over 2-1/2 to 3-1/2
0.032 to 0.165
0.014
Over 2-1/2 to 3-1/2
over 0.165
0.020
Over 3-1/2 to 5
0.035 to 0.165
0.020
Over 3-1/2 to 5
over 0.165
0.025
Over 5 to 7-1/2
0.049 to 0.250
0.025
Over 5 to 7-1/2
over 0.250
0.030
Over 7-1/2 to 16
all
0.00125 In/In of Circumference



ASTM A554 TP316 TOLERANCES — OUTSIDE DIAMETER SQUARE AND RECTANGULAR Tube


Largest Specified
Outside Dimension,
Inches
Wall Thickness,
Inches
OD
± Inches
ASTM A554 316 Tube
To 1-1/4
all
0.015
ASTM A554 316 Tube
Over 1-1/4 to 2
all
0.020
ASTM A554 316 Tube
Over 2-1/2 to 5
all
0.030
ASTM A554 316 Tube
Over 5-1/2
all
0.060



MAXIMUM RADII OF CORNERS

Wall Thickness, Inches
Radii of Corners,
max., in.
Over 0.020 to 0.049, incl
3/32
Over 0.049 to 0.065, incl
1/8
Over 0.065 to 0.083, incl
9.64
Over 0.083 to 0.095, incl
3/16
Over 0.095 to 0.109, incl
13/34
Over 0.109 to 0.134, incl
7/32
Over 0.134 to 0.156, incl
1/4
Over 0.156 to 0.200, incl
3/8
Over 0.200 to 0.250, incl
1/2
Over 0.250 to 0.375, incl
3/4

Note:  For square or rectangular structural Tube with heavier walls, the radius of any outside corner of the section shall not exceed three times the specified wall thickness.



ASTM A554 TP316 TWIST TOLERANCES

Largest Size, Inches
Twist In 3 ft., max, Inches
Under 1/2
0.050
1/2 to 1-1/2 , incl.
0.075
Over 1-1/2 to 2-1/2, incl.
0.095
Over 2-1/2 to 4, incl.
0.125
Over 4 to 6, incl.
0.250
Over 6
0.375



ASTM A554 TP316 STAINLESS STEEL TUBEING PROJECT REFERNCE LIST

YEAR PROJECT – FIELD OF MEMBERSHIP PROJECT – LOCATION SUPPLIED MATERIALS
2017 REFINERY FINLAND A270 Tube, Fittings & Flanges
2017 REFINERY VENEZUELA SMLS AND WELDED CS, LAS, HAS, SS, Pipes, Fittings and Flanges,
2017 POWER PLANT FINLAND SMLS Low Alloy Steel Pipes
2017 REFINERY SWEDEN Stainless Steel Pipes, Fittings & Flanges
2017 PETRO-CHEMICAL PLANT NETHERLANDS Carbon and Stainless Steel Pipes, Fittings & Flanges
2017 REFINERY NETHERLANDS astm a554 tp316 stainless steel Tube, Stainless Steel Pipes, Fittings & Flanges
2017 EXPLORATION AND PRODUCTION NETHERLANDS astm a554 tp316 stainless steel Tube, Stainless Steel Pipes, Fittings & Flanges
2017 CONSTRUCTION HONG KONG Welded and seamless Stainless Steel pipes and mechanical tubes, astm a554 tp316 stainless steel Tube
2017 REFINERY FINLAND A270 Tube & Fittings
2017 REFINERY FINLAND A270 Tube & Fittings
2017 REFINERY CONGO astm a554 tp316 stainless steel Tube, SMLS C.S. API 5L Gr.B / X42 / X52
2017 PETRO-CHEMICAL ITALY SMLS C.S. API 5L Gr.B / X42 / X52, astm a554 tp316 stainless steel Tube,
2017 AMMONIA PLANT ROMANIA astm a554 tp316 stainless steel Tube, SMLS C.S. API 5L X52
2015 REFINERY ANTWERP BELGIUM astm a554 tp316 stainless steel Tube, Fittings, Flanges, Studbolts, Spectacles & Drip Rings acc. EN Standards
2015 REFINERY NETHERLANDS Stainless Steel Pipes, Fittings & Flanges
2015 FPSO BRASIL Inconel / Hastelloy Pipes, astm a554 tp316 stainless steel Tube, Fittings & Flanges
2015 EXPLORATION AND PRODUCTION TURKMENISTAN Inconel / Hastelloy Pipes, astm a554 tp316 stainless steel Tube, Fittings & Flanges
2015 REFINERY FINLAND Low Alloy Steel Pipes and Fittings, astm a554 tp316 stainless steel Tube,
2015 GAS STORAGE IRAQ SMLS AND WELDED C.S. PIPES + HDPE COATED PIPES
2015 REFINERY TURKEY Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel Tube, A270 Tube, astm a554 tp316 stainless steel Tube,
2015 REFINERY ITALY SMLS Carbon, Low Alloy and Stainless steel pipes
2015 POWER PLANT ITALY WELDED Stainless ASTM A240 – TP410S
2014 SULPHUR STORAGE UNITED ARAB EMIRATES Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel Tube, A270 Tube/B, astm a554 tp316 stainless steel Tube,
2014 POWER PLANT BAHRAIN SMLS Alloy ASTM A335/ astm a213tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel Tube, A270 Tube/ astm a213tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel Tube, A270 Tube
2014 POWER PLANT IRAQ astm a554 tp316 stainless steel Tube,SMLS C.S. /Alloy/Stainless ASTM A106/333/312- SMLS C.S. API 5L
2014 PLATFORMS ANGOLA astm a554 tp316 stainless steel Tube, SMLS EN 10210 S355J2H/ WELDED EN10219 S355J2H
2014 REFINERY ITALY WELDED C.S. EN10208-2 L415MB
2014 GAS PIPELINES TUNISIE astm a554 tp316 stainless steel Tube, astm a213tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel Tube, A270 Tube
2014 GAS PIPELINES ITALY astm a554 tp316 stainless steel Tube,SMLS C.S. EN10208-2 L360 NB
2014 UREA PLANT SAUDI ARABIA astm a554 tp316 stainless steel Tube,SMLS Stainless ASTM A312
2014 REFINERY SURINAME astm a554 tp316 stainless steel Tube,astm a213tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel Tube, A270 Tube
2014 OFFSHORE PLATFORM OFFSHORE DUTCH NORTH SEA ( Low Temperature ) Stainless Steel Pipes, Fittings & Flanges
2014 REFINERY NETHERLANDS Hastelloy & Stainless Steel Pipes, Fittings & Flanges
2014 REFINERY NETHERLANDS Stainless Steel Pipes, Fittings & Flanges
2014 REFINERY NETHERLANDS Stainless Steel Pipes, Fittings & Flanges
2014 OFFSHORE PLATFORM OFFSHORE UK NORTH SEA astm a554 tp316 stainless steel Tube, High Yield Pipes & Flanges
2014 OFFSHORE PLATFORM MEDITERRENEAN Welded Stainless ASTM A358, astm a554 tp316 stainless steel Tube
2013 ECOFUEL PLANT ITALY SMLS AND WELDED CS +LTCS PIPES, INCL. COATED PIPES, SMLS STAINLESS ASTM A312 PIPES
2013 GAS PIPELINES NIGERIA Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel Tube, A270 Tube, astm a554 tp316 stainless steel Tube
2013 OIL& GAS PROCESSING AND SEPARATION UNITED ARAB EMIRATES Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel Tube, A270 Tube /API 5L/B
2013 ENI SLURRY TECHNOLOGY PLANT ITALY Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel Tube, A270 Tube
2010 ENVIRONMENTAL SAFEGUARD CITY OF VENICE ITALY astm a554 tp316 stainless steel Tube, SMLS Stainless ASTM A312
2010 PETRO-CHEMICAL PLANT RUSSIA SMLS C.S. /Alloy/Stainless ASTM A333/312/WELDED C.S. /Stainless A671-CC60 CL.32/312/A358 CL. 1
2010 AVIO FUEL DISTRIBUTION ITALY Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2010 GAS STORAGE POLAND Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2010 POWER PLANT BRASIL SMLS Stainless ASTM A312
2010 POWER PLANT BRASIL SMLS Stainless ASTM A312
2010 POWER PLANT ITALY SMLS C.S. /Alloy/Stainless/ASTM A106/335/312/WELDED C.S. API 5L/B
2009 POWER PLANT CHILE Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel Tube, A270 Tube
2009 POWER PLANT CHILE astm a554 tp316 stainless steel Tube, astm a213tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2009 METHANOL PLANT TRINIDAD E TOBAGO SMLS C.S. ASTM API 5L/B/WELDED C.S. API 5L/B/Stainless ASTM A312/A358
2009 GAS PIPELINES ITALY SMLS EN 10208-2/L360NB
2009 CHEMICAL PLANT QATAR Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2009 REFINERY ITALY astm a554 tp316 stainless steel tubing, SMLS C.S. /Alloy/Stainless ASTM A106/335/312
2009 GAS PIPELINES ITALY Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2009 PLATFORMS CONGO Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2009 POWER PLANT ENGLAND Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2008 PETRO-CHEMICAL PLANT RUSSIA SMLS C.S. /Alloy/Stainless ASTM A333/312
2008 PETRO-CHEMICAL PLANT SWEDEN Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2008 REFINERY POLAND SMLS C.S. /A.S. ASTM A106/333/335
2008 OIL PIPELINES ALGERIA Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2008 PLATFORMS TUNISIE Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2008 PLATFORMS GABON Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2008 REFINERY ITALY Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2008 GAS PIPELINES ITALY SMLS EN 10208-2/L360NB
2008 AMMONIA PLANT VENEZUELA Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2008 POWER PLANT ITALY astm a554 tp316 stainless steel tubing, astm a213tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2008 POWER PLANT ITALY astm a554 tp316 stainless steel tubing, SMLS C.S. /Alloy/Stainless/ASTM A106/335/312
2007 AROMATICS PLANT KUWAIT Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2007 PETRO-CHEMICAL PLANT RUSSIA Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2007 REFINERY ITALY Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2007 PETRO-CHEMICAL PLANT RUSSIA Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2007 PETRO-CHEMICAL PLANT GERMANY astm a554 tp316 stainless steel tubing, astm a213tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2007 AMMONIA PLANT TRINIDAD E TOBAGO astm a554 tp316 stainless steel tubing, astm a213tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2007 PETRO-CHEMICAL PLANT TRINIDAD E TOBAGO astm a554 tp316 stainless steel tubing, astm a213tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2007 PETRO-CHEMICAL PLANT TRINIDAD E TOBAGO astm a554 tp316 stainless steel tubing, astm a213tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2007 UREA PLANT TRINIDAD E TOBAGO Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2007 REFINERY MOROCCO SMLS Alloy/Stainless ASTM A335/312
2007 UREA-AMMONIA PLANT PAKISTAN Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2007 METHANOL PLANT EGYPT Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2007 REFINERY LITHUANIA astm a554 tp316 stainless steel tubing, astm a213tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2006 REFINERY MOROCCO Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2006 POWER PLANT ITALY Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2006 POWER PLANT ITALY astm a554 tp316 stainless steel tubing, astm a213tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2006 PETRO-CHEMICAL PLANT QATAR astm a554 tp316 stainless steel tubing, astm a213tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2006 PETRO-CHEMICAL PLANT KSA Asme SA213 tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2006 PETRO-CHEMICAL PLANT KSA astm a554 tp316 stainless steel tubing, astm a213tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2006 PETRO-CHEMICAL PLANT KSA SMLS C.S. /Alloy/ASTM A106/ A333/ A335
2006 POWER PLANT SPAIN astm a554 tp316 stainless steel tubing, Pipes & Fittings
2006 PLATFORMS ITALY astm a554 tp316 stainless steel tubing, astm a213tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing
2006 REFINERY ITALY SMLS/WELDED C.S. /astm a554 tp316 stainless steel tubing, sus 316 square 2205 stainless steel rectangular tube pipes grade 200
2006 PETRO-CHEMICAL PLANT QATAR astm a554 tp316 stainless steel tubing, astm a213tp316 welded AISI 201 316 430 astm a554 tp316 stainless steel tubing, A270 Tubing



ASTM A554 TP316 STAINLESS STEEL TUBE CHEMICAL COMPOSITION

The below table shows the chemical composition of the used for ASTM A554 TP316 Stainless Steel Tubes:

Material UNS C Mn P S Si Cr Ni Mo Ti Nb N
Asme SA 554 316 S31600 0.035 2 0.045 0.03 1 18.0-20.0 8.0-13.0



ASTM A554 TP316 MECHANICAL PROPERTIES

Material Heat Temperure Tensile Strength Yield Strength Elongation %, Min
Treatment Min. Ksi (MPa), Min. Ksi (MPa), Min.
º F(º C)
Asme SA 554 TP316 Solution 1900 (1040) 70(485) 25(170) 35



ASTM A554 TP316 STAINLESS STEEL TUBING PHYSICAL PROPERTIES

Physical properties of ASTM A554 grade TP316 stainless steel in the annealed condition


Grade
Density (kg/m3) Elastic Modulus (GPa) Mean Coefficient of Thermal Expansion (μm/m/°C) Thermal Conductivity (W/m.K) Specific Heat 0-100°C (J/kg.K) Electrical Resistivity (nΩ.m)
0-100°C 0-315°C 0-538°C at 100°C at 500°C
ASTM A554 TP316 8000 193 17.2 17.8 18.4 16.2 21.5 500 720



ASTM A554 TP316 EQUIVALENT

Grade UNS No Old British Euronorm Swedish SS Japanese JIS GOST
BS En No Name
ASTM A554 TP316 S31600 316S31 58E 1.4301 X5CrNi18-10 2332 SUS 316 03Х18Н11



AVAILABLE STOCK OF ASTM A554 TP316 TUBE , ASTM A554 TP316 SS SEAMLESS TUBE

Asme SA 554 316 Stainless Steel Tubing Supplier & Manufacturer in India Asme SA 554 316 Polished Stainless Steel Tubing Supplier & Manufacturer in India
Asme SA 554 316 Welded Tubing Supplier & Manufacturer in India Asme SA 554 316 polished cold rolled welded stainless tube Supplier & Manufacturer in India
Asme SA 554 316 Tubing Manufacturer in India Asme SA 554 316 welded stainless mechanical tubing Supplier & Manufacturer in India
INOX ASTM A554 TP316 Tubing Supplier & Manufacturer in India Asme SA 554 316 Stainless Steel Seamless Tubing Supplier & Manufacturer in India
ASTM A554 TP316 Stainless Steel Square Tubing Supplier & Manufacturer in India ASTM A554 TP316 rectangular tubing Supplier & Manufacturer in India
ASTM A554 316 Stainless Steel Ornamental Tube Supplier & Manufacturer in India ASTM A554 316 Stainless Steel Square Tube Supplier & Manufacturer in India
ASTM A554 316 Stainless Steel Welded Tube Supplier & Manufacturer in India ASTM A554 316 Welded Mechanical Tubing Manufacturer
ASTM A554 316 Square Tubing Supplier & Manufacturer in India ASTM A554 316/316L welded stainless steel mechanical tubing Supplier & Manufacturer in India
ASTM A554 316 Tubing Supplier & Manufacturer in India ASTM A554 Type 316 Stainless Steel Tube Supplier & Manufacturer in India
Asme SA 554 316 Stainless Steel Tubing Supplier & Manufacturer in India Asme SA 554 316 Ornamental Stainless Steel Tube Supplier & Manufacturer in India
ASTM A554 SS 316 Welded Tubes Supplier & Manufacturer in India Asme SA 554 316 Seamless Tube Manufacturer in India
ASTM A554 GR TP316 Tube Manufacturer in India ASTM A554 Grade TP316 Tubing Supplier & Manufacturer in India
Asme SA 554 316 Bright Annealed tubing Supplier & Manufacturer in India Asme SA 554 316 Polished Tubing Supplier & Manufacturer in India
Asme SA 554 316 Stainless Steel Ornamental Tube Supplier & Manufacturer in India Asme SA 554 316 Seamless Stainless Steel Tube Manufacturer
Asme SA 554 316 Stainless Steel Exhaust Tubing Asme SA 554 316 Stainless Steel Round Tubing Supplier & Manufacturer in India
Asme SA 554 316 Ornamental Tubing Manufacturer Asme SA 554 316 Stainless Steel Round Tube Supplier & Manufacturer in India
Asme SA 554 316 Polished Stainless Steel Pipe Supplier & Manufacturer in India Asme SA 554 316 Welded Tubing Exporter
Asme SA 554 316 Steel Tube Supplier & Manufacturer in India Asme SA 554 316 Stainless Steel Mechanical Tube Manufacturer in India
Asme SA 554 316 Stainless Steel Square Tubing Supplier & Manufacturer in India Asme SA 554 316 Polished Stainless Steel Ornamental Tube Exporter
Asme SA 554 316 Welded Stainless Steel Mechanical Tubing Asme SA 554 316 SS Rectangular Tubes Supplier & Manufacturer in India
ASTM A554 UNS S31600 Welded Tubing Supplier & Manufacturer in India ASME SA554 TP316 Welded Stainless Steel Mechanical Tube Supplier & Manufacturer in India



ASTM A554 TP316 STAINLESS STEEL TUBE PRICE LIST
