ASTM A249 TP316L Tube

Kamal Steels is a highly acclaimed supplier, manufacturer, and exporter of SA 249 Tp316l Seamless Tube. ASTM A 249 Tp 316l specification covers nominal-wall-thickness welded tubes and heavily cold worked welded tubes made from the austenitic steels. We offer ASTM A249 Welded Tubes mostly used as boiler, heat exchanger, superheater, condenser tubes.SA 249 Tp316l Seamless Tube has excellent corrosion resistance in ordinary atmospheric conditions, it is easily machined and is also easy to weld. Kamal Steels is India's largest stockholder of ASTM A249 TP316l Stainless Steel Welded Tubes includes ASTM A249 TP316L Stainless Steel Square Tube, ASTM A249 TP316L stainless Steel Condenser tube, ASTM A249 TP316L Stainless Steel rectangular tube, ASTM A249 TP316L Stainless steel oval tube, ASTM A249 TP316L Heat Exchanger tube, ASTM A249 TP316L Superheater Tube and ASTM A249 TP316L Stainless Steel round tube in custom-made sizes and shapes as per the requirements given by our clients, and that too at an affordable and market leading prices.

A249 TP316L Welded Tube

ASTM A249 TP316L Tubing

Table Of Content

SA 249 TP316L ERW Tube Specification
Types of ASTM A249 TP316L Tube
SA 249 Grade TP316L Condenser Tubing Testing
ASTM A249 DIN 1.4404 Tubes Chemical Composition
Mechanical Properties of A249 TP316L Welded Tube
SA 249 Gr 316L Bolier Tube Physical Properties
Equivalent of ASTM A249 316L Tubing
A249 TP316L Heater Tubes Applications

Manufacturer of SA 249 TP316L Welded Tubing in India

SA 249 TP316L ERW Tube Specification

ASTM A249 TP316L welded tube size

1/8” NB to 5” NB

ASTM A249 tp316l SS welded tube OD

6 - 219.1 mm

ASTM A249 tp316l tube wall thickness range

0.5 - 8 mm

ASTM A249 TP316L heat exchanger tube thickness

1mm to 13mm

ASTM A249 tp316l stainless steel tubes standard

SUS, JIS, AISI, ASTM, GB, DIN, EN

ASTM A249 TP316L cold draw welded tubes grades

ASTM A249 TP316L, SA249 TP316L

ASTM A249 TP316L tube finish

No.1 Pickled finish
No.4 finish
BA finish
Electropolished

TP316l A249 welded condenser tube shapes

Round, Rectangular
Square, Hydraulic
Straight, U bend tube
Coiled, Honed tubes

ASTM A249 tp316l tube manufacturing type

Welded
Fabricated
ERW, CEW
CDW / DOM

ASTM A249 tp316 stainless steel tubing end

Plain end
Beveled end
Treaded

ASTM A249 SS 316l welded tube processing service

Bending, Welding
Decoiling, Punching
Cutting, Moulding

ASME SA249 tp316l SS welded tube technique

Cold drawn
Cold , Hot rolled
Extrusion

TP316l tubing value added services

Cutting
Beveling
Threading
Polishing
Ultrasonic testing

ASTM A249 SS 316l tube test certificate

Fumigation
Heat treatment
DFARS compliant
Raw materials
Moisture testing

TP316l SS tubes uses & application

Common industrial services
Fluid, gas and oil industry
Heat transmission
Construction and ornamental
Boilers

SA 249 TP 316L Welded Tube Supplier in Mumbai, View Different Shapes

Types of ASTM A249 TP316L Tube

ASTM A249 316L Stainless Steel Boiler Tube

Stockist of ASTM A249 Grade 316L Condenser Tube, With Testing

SA 249 Grade TP316L Condenser Tubing Testing

Eddy Current Testing
O.P Testing
Radiography Testing
Corrosion Testing
Micro Testing
Macro Testing
IGC Testing
Ultrasonic testing
Liquid Penetrate testing

ASTM A249 DIN 1.4404 Tubes Chemical Composition

Check Chemical Testing of SA 249 Gr 316L Heat Exchanger Tubes

GRADES	UNS	C	Cr	S	Mn	P	Si	Ni
TP316L	S316L00	0.035	18.0-20.0	0.03	2	0.045	1	8.0-13.0

Mechanical Properties of A249 TP316L Welded Tube

Material	Temperure	Yield Strength	Tensile Strength	Heat	Elongation %, Min
	Min.º F(º C)	Ksi (MPa), Min.	Ksi (MPa), Min.	Treatment

TP316L	1900 (1040)	25(170)	70(485)	Solution	35

SA 249 Gr 316L Bolier Tube Physical Properties

Find Typical Properties of SA 249 UNS S31603 Cold Drawn ERW Tube

Grade	Elastic Modulus (GPa)	Mean Coefficient of Thermal Expansion (μm/m/°C)			Thermal Conductivity (W/m.K)		Density (kg/m3)	Specific Heat 0-100°C (J/kg.K)	Electrical Resistivity (nΩ.m)
Grade	Elastic Modulus (GPa)	0-100°C	0-315°C	0-538°C	at 100°C	at 500°C	Density (kg/m3)	Specific Heat 0-100°C (J/kg.K)	Electrical Resistivity (nΩ.m)
316L	193	17.2	17.8	18.4	16.2	21.5	8000	500	720

Equivalent of ASTM A249 316L Tubing

STANDARD	UNS	EN	WERKSTOFF NR.	JIS	BS	GOST	AFNOR
SS 316L	S31603	X2CrNiMo17-12-2 / X2CrNiMo18-14-3	1.4404 / 1.4435	SUS 316L	316LS11 / 316LS13	03Ch17N14M3 / 03Ch17N14M2	Z3CND17‐11‐02 / Z3CND18‐14‐03

A249 TP316L Heater Tubes Applications

Food preparation equipment particularly in chloride environments.
Heat Exchangers.
Coastal architectural paneling, railings trim.
Boat fittings.
Springs.
Threaded fasteners.
Chemical containers, including for transport.
Laboratory benches equipment.
Woven or welded screens for mining, quarrying water filtration.
